Specifications
| General Information | |||
|---|---|---|---|
|
Service tag |
Yes |
Driver Included |
Yes |
| Light Technical | |||
|---|---|---|---|
|
Luminous Flux |
21,500 lm |
Correlated Color Temperature (Nom) |
4000 K |
|
Luminous Efficacy (rated) (Nom) |
140 lm/W |
Color rendering index (CRI) |
70 |
|
Light source color |
740 neutral white |
||
| Operating and Electrical | |||
|---|---|---|---|
|
Input Voltage |
220-240 V |
Input frequency |
50 or 60 Hz |
|
Inrush current |
78 A |
Power Consumption |
150 W |
|
Power Factor (Fraction) |
0.95 |
Connection |
Screw connection block 3-pole |
|
Cable |
– |
Protection class IEC |
Safety class I |
| Controls and Dimming | |||
|---|---|---|---|
|
Dimmable |
Yes |
Control interface |
Analog |
| Approval and Application | |||
|---|---|---|---|
|
Ingress protection code |
IP66 [ Dust penetration-protected, jet-proof] |
Mech. impact protection code |
IK08 [ 5 J vandal-protected] |
| Mechanical and Housing | |||
|---|---|---|---|
|
Housing Material |
Aluminium pressure die cast |
Optical cover material |
Polycarbonate |
|
Overall length |
404 mm
|
Overall width |
230 mm |
|
Overall height |
136 mm |
Optical cover type |
Polycarbonate micro lens optic |
|
Housing Color |
Aluminum and gray
|
Net Weight (Piece) |
4.100 kg
|
| Approval and Application | |||
|---|---|---|---|
|
Ambient temperature range |
-40 to +50 °C |
CE mark |
Yes |
| Initial performance (IEC compliant) | |||
|---|---|---|---|
|
Luminous flux tolerance |
+/-10% |
Power consumption tolerance |
+/-10% |
| Product Data | |||
|---|---|---|---|
|
Full product Name |
BRP492 LED215/NW 150W 220-240V DM GM |
Order product name |
BRP492 LED215/NW 150W 220-240V DM GM |
|
Full product code |
872016972833200 |
Order code |
911401673406 |
|
Numerator – Quantity Per Pack |
1 |
Numerator – Packs per outer box |
1 |
