Specifications
| General Information | |||
|---|---|---|---|
|
Light source engine type |
LED |
Warranty period |
1 Year |
| Operating and Electrical | |||
|---|---|---|---|
|
Input Voltage |
220 to 240 V |
Input frequency |
50 or 60 Hz |
|
Power factor (min.) |
0.9 |
Power Consumption |
16 W |
|
Power Factor (Fraction) |
0.5 |
||
| Controls and Dimming | |||
|---|---|---|---|
|
Dimming |
No |
||
| Mechanical and Housing | |||
|---|---|---|---|
|
Housing Material |
Polycarbonate |
Optical cover material |
Polycarbonate |
|
Housing Color |
White |
Optical cover finish |
Opal |
|
Overall length |
1,174 mm |
Overall width |
28.4 mm |
|
Overall height |
35.7 mm
|
Dimensions (Height x Width x Depth) |
36 x 28 x 1174 mm |
|
Ingress protection code |
IP20 [Finger-protected]
|
Mech. impact protection code |
IK02 [0.2 J standard]
|
|
Optical cover type |
Polycarbonate
|
Net Weight (Piece) |
0.142 kg
|
| Light Technical | |||
|---|---|---|---|
|
Luminous Flux |
1,600 lm |
Correlated Color Temperature (Nom) |
6500 K |
|
Luminous Efficacy (rated) (Nom) |
100 lm/W |
Color rendering index (CRI) |
>70 |
|
Light source color |
765 cool daylight |
||
| Approval and Application | |||
|---|---|---|---|
|
IPxx |
IP65 [ Dust penetration-protected, jet-proof] |
IKxx |
IK08 [ 1 J] |
| Initial performance (IEC compliant) | |||
|---|---|---|---|
|
Luminous flux tolerance |
+/-10% |
Power consumption tolerance |
+/-10% |
| Application Conditions | |||
|---|---|---|---|
|
Ambient temperature range |
-20 to +40 °C |
|
|
| Product Data | |||
|---|---|---|---|
|
Full product code |
871951451455399 |
Order product name |
BN016C LED16/CW L1200 GM G2 |
|
EAN/UPC – product |
8719514514553 |
Order code |
911401893481 |
|
Numerator – Packs per outer box |
40 |
||
